Hydraulic Pile Hammer

Specifications

Hydraulic Pile Hammer

  • The hydraulic rotary motor and gear are built-in, which can effectively avoid oil pollution and collision. The gears are convenient for replacement, closely matched, stable and durable.
  • The box adopts an open structure to ensure pressure balance and stable heat discharge in the box.
  • It adopts high performance imported damping rubber block, which has stable quality and long service life.
  • It uses original imported hydraulic motor, which is stable in efficiency and outstanding in quality.
  • The tong cylinder has strong thrust and keeps the pressure. It is stable and reliable to ensure that the pile body is not loose and guarantee the construction safety.
  • The tong is made of imported wear-resistant sheet with stable performance and long service cycle.



Applicable Sheet Pile Length

Parameters
Model S250 S350 S500 S600 S650 S800 S900 S1100
Vibration Frequency(rpm) 3200 3000 2800 2800 2700 2900 2700 2300
Eccentricity Moment Torque(nm) 22 36 52 70 83.5 84 110 180
Rated excitation force(kn) 250 360 450 600 650 800 900 1100
Hydraulic system pressure(mpa) 32 32 35 35 35 35 35 35
Hydraulic system flow rating(lpm) 106 247 270 318 306 380 450 380
Maximum pile length(m) 6-9 6-9 6-15 6-15 6-18 6-24 6-24 6-36
The auxiliary arm weight(kg) 700 800 800 900 900 1300 1300 1300
Total Weight(kg) 1250 1950 2750 2850 3200 3800 4100 4500
Suitable Excavator(ton) 15-20 20-28 30-38 42-50 42-50 50-70 50-70 70-90
